NVIDIA® Quadro® 4000 by PNY - Accelerate your entire workflow

Offering 2 GB of GDDR5 graphics memory, 256 NVIDIA CUDA™ parallel processing cores and built on the innovative Fermi architecture, the NVIDIA Quadro 4000 by PNY is a true technological breakthrough delivering excellent performance across a broad range of design, animation and video applications. Using the Quadro 4000 graphics solution, your work flows — you can design, render and deliver higher quality projects in less time.

The NVIDIA Quadro 4000 by PNY graphics board significantly raises the bar for high performance visualization and computation providing Microsoft DirectX 11.0, OpenGL 4.0 and Shader Model 5.0 hardware acceleration, and the ability to drive a variety of display types including: CRTs, Digital Flat Panels, Projectors and HDTVs.

GPU Memory Size	2 GB GDDR5
Memory Interface	256-bit
Memory Bandwidth	89.6 GB/sec
CUDA Parallel Processing Cores	256
Display Connectors	DVI-DL+ DP + DP +ST
Warranty	3 Years
PNY Part #	VCQ4000-PB

PNY provides unsurpassed service and commitment to its professional graphics customers offering: 3 year warranty, pre and post sales support, dedicated Quadro Field Application engineers and direct tech support hot lines. In addition, PNY delivers a complete solution including the appropriate adapters, cables, brackets, driver CD and documentation to ensure a quick and successful install.

Frame Buffer Memory	2 GB GDDR5
Memory Interface	256-bit
Memory Bandwidth	89.6 GB/s
CUDA parallel processing cores	256
High Performance Double Precision	Yes
Max Power Consumption	142 W
Physical Dimensions	4.376” H x 9.50” L Single Slot
Display Connectors	DVI-I (1), DP (2), Stereo (1 optional)
Number of Displays Supported	2
DisplayPort	Yes
DVI	Yes
VGA	Yes
Graphics Bus	PCI Express 2.0 x16
Form Factor	4.376” H x 9.50” L Single Slot
Thermal Solution	Active
3D Vision Pro	Support via 3 pin mini DIN
HD-SDI Capture/Output	Version Available
Warranty	3 Year Warranty
PNY Part #	VCQ4000-PB



TECHNICAL SPECIFICATIONS

Supported Platforms

• Microsoft Windows 7 (64-bit and 32-bit)
• Microsoft Windows Vista (64-bit and 32-bit)
• Microsoft Windows XP (64-bit and 32-bit)
• Linux® - Full OpenGL implementation, complete with NVIDIA and ARB extensions (64-bit and 32-bit)
• Solaris®

3D Graphics Architecture

• Scalable geometry architecture
• Hardware tessellation engine
• NVIDIA® GigaThread™engine with dual copy engines
• Shader Model 5.0 (OpenGL 4.0 and DirectX 11)
• Optimized compiler for Cg and Microsoft HLSL
• Up to 16K x16K texture and render processing
• Transparent multisampling and super sampling
• 16x angle independent anisotropic filtering
• 128-bit floating point performance
• 32-bit per-component floating point texture filtering and blending
• 64x full scene antialiasing (FSAA)/128x FSAA in SLI Mode
• Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, MVC, VC1, DivX (version 3.11 and later), and Flash (10.1 and later)
• Blu-ray dual-stream hardware acceleration (supporting HD picture-in-picture playback)

NVIDIA CUDA Parallel Processing Architecture

• API support includes:
  - CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
• NVIDIA® Parallel DataCache™ hierarchy (configurable L1 and unified L2 caches)
• 64 KB of RAM (configurable partitioning of shared memory and L1 cache)
• Full IEEE 754-2008 - 32-bit and high performance 64-bit double precision
• Dual Warp Scheduler (schedules and dispatches simultaneously instructions from two independent warps)

Advanced Display Features

• 30-bit color (10-bit per each red, green, blue channel)
• Support for any combination of two connected displays
• Dual DisplayPort (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
• Dual-link DVI-I output (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
• Internal 400 MHz DAC DVI-I output (analog display up to 2048 x 1536 @ 85Hz)
• DisplayPort to VGA, DisplayPort to DVI (single-link and dual-link) and DisplayPort to HDMI cables (resolution support based on dongle specifications)
• DisplayPort 1.1a, HDMI 1.3a, and HDCP support
• 10-bit internal display processing (hardware support for 10-bit scanout for both windowed desktop and full screen, only available on Windows and Linux with Aero disabled)
• NVIDIA® 3D Vision™ technology, 3D DLP, Interleaved, and other 3D stereo format support
• Full OpenGL quad buffered stereo support
• Underscan/overscan compensation and hardware scaling
• NVIDIA® nView® multi-display technology

DisplayPort and HDMI Digital Audio

• Support for the following audio modes:
  - Dolby Digital (AC3), DTS 5.1, Multi-channel (7.1) LPCM, Dolby Digital Plus (DD+), andMPEG-2/MPEG-4 AAC
• Data rates of 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176 KHz, and 192 KHz
• Word sizes of 16-bit, 20-bit, and 24-bit



Minimum System Requirements

• Intel® Core i5, i7 or Xeon processor, or AMD Phenom® or Opteron® class processor
• PCIe x16 expansion slot
• Windows® 7 (any Edition), Vista (any edition), XP (Home or Professional), or Linux
• 1GB or more of system memory, 2GB recommended
• 100MB of available disk space for full driver installation
• Blu-ray, DVD-ROM or CD-ROM drive
• DisplayPort, DVI or VGA compatible display(s)
• Download the latest Quadro drivers

Big Advantage. Big Savings. BUY TODAY & SAVE $50

Get the most out of your professional application with the NVIDIA® Quadro® 4000 by PNY. Take advantage of this great offer starting May 7, 2012 through July 31, 2012 when you buy the NVIDIA® Quadro® 4000 by PNY from Videoguys.com. Download your Mail-in Rebate Form

#4 - NVIDIA Quadro 4000 by PNY

When Adobe worked with NVIDIA to create the CS5 Mercury Playback Engine, they made it more important than ever to choose the best graphics board for your NLE workstation.  In the past, when manufacturers required special graphics cards, they were often extremely expensive. Now, the NVIDIA Quadro 4000  by PNY is an incredibly powerful board for under $1,000 and it's available for either PC or Mac! While the Quadro4000 Mac costs a little more than it's PC brother, it is substantially less expensive than any other Quadro board ever offered for Mac.

The Quadro 4000 is based on NVIDIA's Fermi technology, which is the next generation of their CUDA technology. This is an understatement, it's more like CUDA on steroids. The Fermi/CUDA power allows software vendors to tap directly into the GPUs many processing cores. The Quadro 4000 has a whopping 256 CUDA Parallel Processing Cores to go along with it's 2GB of GDDR5 memory.  Think about that, it's like having a dedicated graphics workstation on a card. The folks at Adobe jumped on this and other software manufacturers in the content creation and encoding business are following along. When you put a Quadro 4000 in your PC or Mac workstation, you're making sure that you'll have the GPU CUDA performance to take full advantage of these new performance enhancements as they become available in more and more applications.

Click here for related guides & articles about the Adobe Mercury Playback Engine and the Quadro boards using the "Mercury" hot tag

---

For years we have been recommending NVIDIA Quadro professional graphics boards to our professional customers who demand the highest level of performance, reliability and stability. Quadro cards cost a bit more than your average gaming graphics card, but for professional content creators, the extra cost is often worth it. In a nut shell, many tech support issues we run into are graphics card related. While you may be able to save some bucks going with a gaming card, we feel confident that if you invest in a Quadro4000, you'll be happy you did!

The world's best under $1,000 graphics card for the Adobe CS5 Mercury Playback Engine!

With the introduction of the Mercury Playback Engine, Adobe Premiere Pro CS5 becomes the world's first CUDA optimized NLE solution.  The Quadro 4000 taps into the new Fermi technology, which is basically CUDA on steroids. For under $900 the Quadro4000 delivers performance that blows away the almost twice as expensive QuadroFX4800 cards. The Quadro 4000 for MAC is the must have upgrade for Mac based Adobe CS5 users. Now, for under $1,000, you can edit multiple layers of native DSLR or AVCHD  footage, plus incredible graphics performance with Photoshop, After Effects and all the other software in the Adobe CS5 Production Premium.

Design, iterate, and deliver in less time
The Quadro 4000 is the first professional graphics solution in its class to integrate high-performance computing with advanced visualization, transforming modern workflows. Delivering up to 5x faster performance, the Quadro 4000 professional graphics solution drives a broad range of design, animation and video applications. With Scalable Geometry Engine™ technology, Quadro 4000 can process up to 890 million triangles per second, enabling professionals to design, iterate and deliver higher quality results in less time

Unleash the creativity in your editing suite
Blockbuster films are not made overnight, but with Adobe Premiere® Pro CS5 and NVIDIA® Quadro® graphics solutions, editing time can be drastically reduced. At the heart of Premiere Pro CS5 is the Adobe Mercury Playback Engine – built using the NVIDIA® CUDA™ parallel processing architecture – so Quadro GPUs deliver real-time previewing and editing of native, high-resolution footage, including multiple layers of RED 4K video.

Whether you're working on independent films or corporate videos, you are no doubt under tight deadlines, and stringent budget constraints. However, Quadro professional graphics solutions easily transform a workstation into a high-end post production system, at a fraction of the cost. With boosted performance and amazingly fluid, real-time video editing, you can feel confident to work your magic in front of a client, rather than having to endure the painful wait for your effects to render. Leaving one real question - what do you do with all that extra time?

• Refine and apply multiple color corrections and  effects, in HD and higher-resolution sequences, with smooth scrubbing and playback – all in real-time!
• Experience rich, vivid image quality with the broadest dynamic range with 30-bit color fidelity.
• Work in real-time on complex timelines and large projects with thousands of clips – whether your source is SD, HD, 2K, 4K or beyond.
•  Easily integrate project files from After Effects and Photoshop into Premiere Pro and edit in real-time.
• Designed by NVIDIA, built by NVIDIA, and directly supported by NVIDIA with an extended  three year warranty.
